Specifications |
|
|---|---|
| Pallet Size | 23.75" x 15.7" |
| Number of Pallets | 2 |
| Pallet Load Capacity | 374 pounds |
| X-Axis Travel | 20 inches |
| Y-Axis Travel | 12.5 inches |
| Z-Axis Travel | 11.8 inches |
| Spindle Speed | 10,000 RPM |
| Main Motor | 7.5 HP/10HP (15min) / 15HP (10 min) |
| Spindle Nose to Table | 8.6" - 20.5" |
| Spindle Center to Z-Axis Way Cover | 12.9 inches |
| Pallet Change Time | 3.5 Seconds |
| Magazine Tool Capacity | 30 ATC |
| Spindle Taper | CAT 40 |
| Maximum Tool Weight | 13.2 pounds |
| Maximum Tool Diameter | 3.0" / 4.0" Adjacent Empty |
| Tool Change Time | 2.5 Seconds Tool to Tool |
| X-Axis Rapid Traverse Rate | 1890 IPM |
| Y-Axis Rapid Traverse Rate | 1890 IPM |
| Z-Axis Rapid Traverse Rate | 1890 IPM |
| Cutting Feed | 394 IPM |
| Dimensions | 83" x 132" x 101" H |
| Weight | 12320 pounds |
