Specifications |
|
|---|---|
| Table Length | 34" |
| Table Width | 9.5" |
| Table T-Slots | (3) - Along X-Axis of Table |
| Table T-Slot Width | 5/8" |
| T-Slot Center to Center Distance | 2-3/8" |
| Weight | 1130 pounds |
| Maximum Weight on Table | 500 lbs. |
| Spindle Nose to Table (Max) | 17" |
| Spindle Nose to Table (Min) | 1" |
| Spindle Center to Column Face | 11" |
| X-Axis Travel | 18" |
| Y-Axis Travel | 9.5" |
| Z-Axis Travel | 16.5" |
| Spindle Speed Range | 100 - 5,140 RPM |
| Spindle Rating | 1.5 HP (2 HP Peak) |
| Spindle Drive | Belt Driven (Low Belt - 100-2,000 RPM / High Belt - 250-5,140 RPM) |
| Spindle Taper | R-8 |
| Rapid Feed Rates | 110 IPM X-Axis / 110 IPM Y-Axis / 90 IPM Z-Axis |
| Maximum Cutting Feed Rates | 110 IPM X-Axis / 110 IPM Y-Axis / 90 IPM Z-Axis |
| Power Requirements | 200 - 250 VAC Single Phase |
| Machine Space Requirements | 67" W x 43" D x 84" H |
