Pandjiris Model 1600 Welding Manipulator

Specifications

Horizontal Boom Stroke 16 feet
Vertical Boom Lift Range 26.375" - 16'8.375
Max. Height Under Boom 18'9"
Weight Capacity 1100 pounds
Boom Lift Speed 32 IPM
Horizontal Boom Speed 3 - 116 IPM
Column Rotation Range (Manual) 360 Deg.
Base Dimensions 40" x 40"

Equipped With


  • Heavy Duty Pandjiris 415P 6" Vertical & Horizontal Cross Slides

  • 180 Deg. Weld Orientation Swivel

  • Spring Loaded, Self-Energizing Pawl Mounted on the Cross Head Engages Column Face

  • 25' Hand Pendant Control

  • 21' 9" Total Height

  • MIG Package: $13,000.00 Includes - Lincoln Power Wave 455M Power Supply, Power Feeder 10M Control & Feeder

  • TIG Package: $8,000.00 Includes - Custom Podium Control, Jetline Cold Wire Feeder & ALC

  • 460V, 3 Phase
