Specifications |
|
|---|---|
| X-Axis (With Angle & Rotary Table) | 53.2 inches |
| Y-Axis | 45.3 inches |
| Z-Axis (With Vertical Spindle) | 26.9 inches |
| Z-Axis (With Horizontal Spindle) | 34.3 inches |
| Throat Distance | 27.6 inches |
| Table Diameter | 43.3 inches |
| Table Load Capacity | 3300 pounds |
| Table Indexing (Direct Drive) | 0.001 Degrees |
| Spindle Swivel (Simultaneous) | +15 / -120 Degrees |
| Spindle Speeds | 12,000 RPM |
| Spindle Taper | DIN-40 |
| Spindle Drive Motor | 32 HP |
| Rapid Traverse (X, Y, Z) | 1,180 IPM |
| Feedrate (X, Y, Z) | 0-394 IPM |
| Maximum Tool Diameter x Length | 3.14" x 11.8" |
| Approximate Dimensions | 163" x 145" x 124" |
| Approximate Weight | 25360 pounds |
