Specifications |
|
|---|---|
| Table Size | 35.4" x 116.1" |
| Table Load Capacity | 7,700 lbs. |
| Distance Between Columns | 49.05" |
| Spindle Nose to Table | 9.9" - 37.9" |
| X-Axis Travel | 98.4 inches |
| Y-Axis Travel | 42.7 inches |
| Z-Axis Travel | 28 inches |
| Rapid Traverse Rate (X/Y/Z) | 945/945/945 IPM |
| Spindle Speed | 10,000 RPM |
| Spindle Taper | CAT-50 Big-Plus |
| Number of Gear Ranges | 2 |
| Main Motor | 30 HP |
| Automatic Tool Changer | 40 Positions |
| Maximum Tool Diameter | 6" |
| Maximum Tool Length | 13.7" |
| Maximum Tool Weight | 33 lbs. |
| Approximate Machine Weight | 37400 pounds |
