Specifications |
|
|---|---|
| Maximum Workpiece Diameter | 9.84" (250 mm) |
| Maximum Boring Bar Depth | 6.89" (175 mm) |
| Spindle Thru-Hole | 3.03" (77 mm) |
| Spindle Nose | A2-8 |
| Spindle Speed Range | 40 - 3,150 RPM |
| Z-Axis (Carriage) Stroke | 15.75" |
| Z-Axis Rapid Traverse | 472 IPM |
| X-Axis (Tool Slide) Stroke | 8.07" (205 mm) |
| X-Axis Rapid Traverse | 393.7 IPM |
| X-Axis Feed Range | 0.04 - 393.7 IPM |
| Main Spindle Rotary Feed (C-Axis) Rapid Traverse | 20 RPM |
| Main Spindle Rotary Feed (C-Axis) Least Input | 0.001 Degree |
| Turret Capacity | 12 |
| Main Spindle Motor | 24.80 HP - Continuous / 29.5 HP - 30 Minutes |
| Live Tooling | yes |
| Live Tool Motor | 2.95 HP - Continuous / 4.96 HP - 30 Minutes |
| Coolant Tank Capacity | 31.7 Gallons |
