Specifications |
|
|---|---|
| Swing Over Bed | 29.5 inches |
| Turning Dia. | 21.25 inches |
| Turning Length | 52 inches |
| Distance Bewtween Spindles | 52.5 inches |
| Chuck Size 1, 2 | 8 inches |
| Spindle Nose 1,2 | A2-6, A2-6 |
| Bar Capacity 1, 2 | 2.6" / 2.5" |
| Spindle Speeds 1, 2 | 5,000 RPM, 5,000 RPM |
| Spindle HP 1, 2 | 30 HP / 30HP |
| B-Axis Head Indexing | 0.001 Deg. |
| B-Axis Milling Spindle Speed | 12000 RPM |
| B-Axis Milling Spindle Taper | Capto C6 |
| B-Axis Milling Spindle HP | 25 HP |
| ATC Milling Spindle | 40 Position |
| Max. Tool Dia. | 3.54" / 4.72" |
| Max Tool Length | 11.8" |
| Max Tool Weight | 17.6 pounds |
| X-Axis Travel X1/X2/X3 | 22.24" / 7.36" |
| Z-Axis Travel Z1/Z2/Z3 | 41.3" / 41.3" |
| Y-Axis Travel Y1/Y2/Y3 | 6.7" |
| C-Axis Indexing 1, 2 | 0.001 Deg. / 0.001 Deg. |
| W-Axis Travel (Sub-Spindle) | 41.3 inches |
| Rapid Traverse X1/X2/X3 | 1417 IPM |
| Rapid Traverse Z1/Z2/Z3 | 1417 IPM |
| Rapid Traverse Y1/Y2/Y3 | 1024 IPM |
| Turret Tool Positions 1/2/3 | 12 Lower |
| Turret Rotary Tool Speeds | 5000 RPM |
| Turret Rotary Tool HP | 7.5 HP |
| Approximate Machine Weight | 26450 pounds |
