Specifications |
|
|---|---|
| Swing Over Bed | 27.95 inches |
| Swing Over Carriage | 17 inches |
| Maximum Turning Diameter | 23.62 inches |
| Maximum Turning Length | 98.42 inches |
| Maximum Load Capacity | 5512 pounds |
| Spindle Speed Steps | Auto 3 |
| Spindle Speeds | 28 - 2,000 RPM |
| Spindle Nose | A1-11 |
| Hole Thru Spindle | 4 inches |
| Maximum Loading Capacity, Chuck Only | 1323 pounds |
| X Axis Travel | 15 inches |
| Z Axis Travel | 83 inches |
| Rapid Traverse (X/Z) | 326 / 472 IPM |
| Tailstock Taper | MT#6 |
| Tailstock Quill | 4.4 inches |
| Tailstock Quill Movement | Manual Hook Type |
| Main Motor | 25 HP |
| Weight | 18000 pounds |
